Binding: 健保事前審查-臺灣健保署2023年中文版ICD 10 PCS-影像報告值集 ( preferred ): 最新參考代碼清單請參考 此檔案 。
Binding: 健保事前審查-臺灣健保署2023年中文版ICD 10 PCS-影像報告值集 ( extensible ): 最新參考代碼清單請參考 此檔案 。
Binding: 健保事前審查-臺灣健保署2014年中文版ICD 10 PCS-影像報告值集 ( extensible ): 最新參考代碼清單請參考 此檔案 。
Binding: LOINC-健保事前審查-報告類型值集 ( extensible ): 最新參考代碼清單請參考 此檔案 。
speType: 當報告類型(code.coding.code)為`47526-9`時，檢體種類(code.text)必填
Binding: SCT + NCI-健保事前審查-癌症分期量表項目值集 ( extensible ): 最新參考代碼清單請參考 此檔案 。
Binding: LOINC-健保事前審查-基因檢測代碼值集 ( extensible ): 最新參考代碼清單請參考 此檔案 。
Binding: LOINC-健保事前審查-基因突變類型值集 ( extensible ): 最新參考代碼清單請參考 此檔案 。
pas-1: text、coding擇一填寫。
Binding: LOINC + NHI-健保事前審查-病人狀態評估項目值集 ( extensible ): 最新參考代碼清單請參考 此檔案 。
Binding: 健保事前審查-臺灣健保署2023年中文版ICD 10 PCS-放射治療項目值集 ( preferred ): 最新參考代碼清單請參考 此檔案 。
Binding: 健保事前審查-臺灣健保署2023年中文版ICD 10 PCS-放射治療項目值集 ( extensible ): 最新參考代碼清單請參考 此檔案 。
Binding: 健保事前審查-臺灣健保署2014年中文版ICD 10 PCS-放射治療項目值集 ( extensible ): 最新參考代碼清單請參考 此檔案 。
Binding: 健保事前審查-臺灣健保署2023年中文版ICD 10 PCS-放射治療項目值集 ( preferred ): 最新參考代碼清單請參考 此檔案 。
Slice: Unordered, Open by type:$this
Binding: 健保事前審查-臺灣健保署2023年中文版ICD 10 PCS-放射治療項目值集 ( preferred ) : 最新參考代碼清單請參考 此檔案 。
http://dicom.nema.org/resources/ontology/DCM
| Code | Display | Definition |
BMD
|
Bone Mineral Densitometry | An acquisition device, process or method that performs bone mineral densitometry by X-Ray, including dual-energy X-Ray absorptiometry (DXA) and morphometric X-Ray absorptiometry (MXA). |
EOG
|
Electrooculography | An acquisition device, process or method that performs electrooculography. |
SM
|
Slide Microscopy | An acquisition device, process or method that performs slide microscopy. |
OP
|
Ophthalmic Photography | An acquisition device, process or method that performs ophthalmic photography. |
ECG
|
Electrocardiography | An acquisition device, process or method that performs electrocardiography. |
GM
|
General Microscopy | An acquisition device, process or method that performs general microscopy. |
XA
|
X-Ray Angiography | An acquisition device, process or method that performs X-Ray angiography. |
XC
|
External-camera Photography | An acquisition device, process or method that performs photography with an external camera. |
DMS
|
Dermoscopy | An acquisition device, process or method that performs imaging of the surface of the skin using epiluminescence microscopy. |
IVUS
|
Intravascular Ultrasound | An acquisition device, process or method that performs intravascular ultrasound. |
CR
|
Computed Radiography | An acquisition device, process or method that performs computed radiography. |
CT
|
Computed Tomography | An acquisition device, process or method that performs computed tomography. |
OSS
|
Optical Surface Scanner | An acquisition device, process or method that performs optical surface scanning. |
TG
|
Thermography | An acquisition device, process or method that performs thermography. |
LEN
|
Lensometry | An acquisition device, process or method that performs lensometry. |
OPTENF
|
Ophthalmic Tomography En Face | An acquisition device, process or method that creates en face tomography images of the eye based on light and optical principles. Tomography based on other principles, such as ultrasound, is excluded. |
HD
|
Hemodynamic Waveform | An acquisition device, process or method that records hemodynamic waveforms. |
OCT
|
Optical Coherence Tomography | An acquisition device, process or method that uses an interferometric, non-invasive optical tomographic technique to image 2D slices and 3D volumes of tissue using visible and near visible frequencies. |
BDUS
|
Ultrasound Bone Densitometry | An acquisition device, process or method that performs ultrasound bone densitometry. |
DG
|
Diaphanography | An acquisition device, process or method that performs diaphanography. |
PT
|
Positron emission tomography | An acquisition device, process or method that performs positron emission tomography (PET). |
EPS
|
Cardiac Electrophysiology | An acquisition device, process or method that performs cardiac electrophysiology. |
LS
|
Laser Scan | An acquisition device, process or method that performs laser surface scanning. |
PX
|
Panoramic X-Ray | An acquisition device, process or method that performs panoramic X-Rays. |
OPM
|
Ophthalmic Mapping | An acquisition device, process or method that measures corneal topography, corneal or retinal thickness, and other similar parameters that are typically displayed as maps. |
OPTBSV
|
Ophthalmic Tomography B-scan Volume Analysis | An acquisition device, process or method that performs B-scan volume analysis of tomography images of the eye based on light and optical principles. Tomography based on other principles, such as ultrasound, is excluded. |
OPV
|
Ophthalmic Visual Field | An acquisition device, process or method that measures visual fields and perform visual perimetry. |
DX
|
Digital Radiography | An acquisition device, process or method that performs digital radiography. |
OPT
|
Ophthalmic Tomography | An acquisition device, process or method that performs tomography of the eye that is based on light and optical principles. Tomography based on other principles, such as ultrasound, is excluded. |
MG
|
Mammography | An acquisition device, process or method that performs mammography. |
US
|
Ultrasound | An acquisition device, process or method that performs ultrasound. |
EMG
|
Electromyography | An acquisition device, process or method that performs electromyography. |
IVOCT
|
Intravascular Optical Coherence Tomography | An acquisition device, process or method that performs intravascular optical coherence tomography |
MR
|
Magnetic Resonance | An acquisition device, process or method that performs magnetic resonance imaging. |
IO
|
Intra-oral Radiography | An acquisition device, process or method that performs intra-oral radiography. |
EEG
|
Electroencephalography | An acquisition device, process or method that performs electroencephalography. |
RTIMAGE
|
RT Image | An acquisition device, process or method that performs radiotherapy imaging; includes portal imaging. |
VA
|
Visual Acuity | An acquisition device, process or method that measures visual acuity. |
RESP
|
Respiratory Waveform | A device, process or method that produces waveforms of electrical signals from the patient’s respiratory system. |
ES
|
Endoscopy | An acquisition device, process or method that records images during endoscopy. |
AR
|
Autorefraction | An acquisition device, process or method that measures autorefraction. |
POS
|
Position Sensor | A device or sensor measuring the orientation of the patient’s body. |
RG
|
Radiographic imaging | An acquisition device, process or method that performs radiographic imaging (conventional film/screen). |
RF
|
Radiofluoroscopy | An acquisition device, process or method that performs radiofluoroscopy. |
KER
|
Keratometry | An acquisition device, process or method that performs keratometry. |
OAM
|
Ophthalmic Axial Measurements | An acquisition device, process or method that measures the axial length of the eye. |
NM
|
Nuclear Medicine | An acquisition device, process or method that performs nuclear medicine imaging. |
BI
|
Biomagnetic Imaging | An acquisition device, process or method that performs biomagnetic imaging. |
SRF
|
Subjective Refraction | An acquisition device, process or method that records subjective refraction. |
Links: Table of Contents | QA Report
Show Usage
Binding: 健保事前審查-臺灣健保署2023年中文版ICD 10 PCS-影像報告值集 ( preferred ): 最新參考代碼清單請參考 此檔案 。
ele-1: All FHIR elements must have a @value or children
Binding: 健保事前審查-臺灣健保署2023年中文版ICD 10 PCS-影像報告值集 ( extensible ): 最新參考代碼清單請參考 此檔案 。
ele-1: All FHIR elements must have a @value or children
Binding: 健保事前審查-臺灣健保署2014年中文版ICD 10 PCS-影像報告值集 ( extensible ): 最新參考代碼清單請參考 此檔案 。
ele-1: All FHIR elements must have a @value or children
Binding: 健保事前審查-臺灣健保署2023年中文版ICD 10 PCS-影像報告值集 ( extensible ): 最新參考代碼清單請參考 此檔案 。
Binding: 健保事前審查-臺灣健保署2014年中文版ICD 10 PCS-影像報告值集 ( extensible ): 最新參考代碼清單請參考 此檔案 。
Binding: LOINC-健保事前審查-報告類型值集 ( extensible ): 最新參考代碼清單請參考 此檔案 。
ele-1: All FHIR elements must have a @value or children
speType: 當報告類型(code.coding.code)為`47526-9`時，檢體種類(code.text)必填
( required to
http://www.rsna.org/RadLex_Playbook.aspx
)
( extensible to
http://www.rsna.org/RadLex_Playbook.aspx
)
( required to
http://www.rsna.org/RadLex_Playbook.aspx
)
( extensible to
http://dicom.nema.org/medical/dicom/current/output/chtml/part04/sect_B.5.html#table_B.5-1
)
Binding: http://www.rsna.org/RadLex_Playbook.aspx ( extensible ): 此資料項目為可擴充綁定預設國際標準值集，但實作者可視實務專案需求只綁定以下slices中的任一值集。目前未只限定綁定預設值集是因為尚無slice值集與預設國際標準值集的代碼對應表，待後續有相對的代碼對應表後將建議採用國際標準值集作為唯一綁定值集並針對該值集進行擴充與管理，以利進行跨國與跨系統之資料交換。
ele-1: All FHIR elements must have a @value or children
Binding: http://www.rsna.org/RadLex_Playbook.aspx ( required )
ele-1: All FHIR elements must have a @value or children
Binding: http://dicom.nema.org/medical/dicom/current/output/chtml/part04/sect_B.5.html#table_B.5-1 ( extensible ): 應填入所綁定值集中適合的代碼，確定無適合的代碼才可以使用其他值集的代碼來表示。
ele-1: All FHIR elements must have a @value or children
http://www.rsna.org/RadLex_Playbook.aspx
http://dicom.nema.org/medical/dicom/current/output/chtml/part04/sect_B.5.html#table_B.5-1
Binding: http://www.rsna.org/RadLex_Playbook.aspx ( extensible ): 此資料項目為可擴充綁定預設國際標準值集，但實作者可視實務專案需求只綁定以下slices中的任一值集。目前未只限定綁定預設值集是因為尚無slice值集與預設國際標準值集的代碼對應表，待後續有相對的代碼對應表後將建議採用國際標準值集作為唯一綁定值集並針對該值集進行擴充與管理，以利進行跨國與跨系統之資料交換。
Binding: http://www.rsna.org/RadLex_Playbook.aspx ( required )
Binding: http://dicom.nema.org/medical/dicom/current/output/chtml/part04/sect_B.5.html#table_B.5-1 ( extensible ): 應填入所綁定值集中適合的代碼，確定無適合的代碼才可以使用其他值集的代碼來表示。
Binding: SCT + NCI-健保事前審查-癌症分期量表項目值集 ( extensible ): 最新參考代碼清單請參考 此檔案 。
ele-1: All FHIR elements must have a @value or children
Binding: LOINC-健保事前審查-基因檢測代碼值集 ( extensible ): 最新參考代碼清單請參考 此檔案 。
ele-1: All FHIR elements must have a @value or children
Binding: LOINC-健保事前審查-基因突變類型值集 ( extensible ): 最新參考代碼清單請參考 此檔案 。
ele-1: All FHIR elements must have a @value or children
pas-1: text、coding擇一填寫。
Binding: LOINC-健保事前審查-基因檢測代碼值集 ( extensible ): 最新參考代碼清單請參考 此檔案 。
Binding: LOINC + NHI-健保事前審查-病人狀態評估項目值集 ( extensible ): 最新參考代碼清單請參考 此檔案 。
ele-1: All FHIR elements must have a @value or children
Binding: 健保事前審查-臺灣健保署2023年中文版ICD 10 PCS-放射治療項目值集 ( preferred ): 最新參考代碼清單請參考 此檔案 。
ele-1: All FHIR elements must have a @value or children
Binding: 健保事前審查-臺灣健保署2023年中文版ICD 10 PCS-放射治療項目值集 ( extensible ): 最新參考代碼清單請參考 此檔案 。
ele-1: All FHIR elements must have a @value or children
Binding: 健保事前審查-臺灣健保署2014年中文版ICD 10 PCS-放射治療項目值集 ( extensible ): 最新參考代碼清單請參考 此檔案 。
ele-1: All FHIR elements must have a @value or children
Binding: 健保事前審查-臺灣健保署2023年中文版ICD 10 PCS-放射治療項目值集 ( extensible ): 最新參考代碼清單請參考 此檔案 。
Binding: 健保事前審查-臺灣健保署2014年中文版ICD 10 PCS-放射治療項目值集 ( extensible ): 最新參考代碼清單請參考 此檔案 。
Binding: 健保事前審查-臺灣健保署2023年中文版ICD 10 PCS-放射治療項目值集 ( preferred ): 最新參考代碼清單請參考 此檔案 。
ele-1: All FHIR elements must have a @value or children
Slice: Unordered, Open by type:$this
Binding: 健保事前審查-臺灣健保署2023年中文版ICD 10 PCS-放射治療項目值集 ( preferred ) : 最新參考代碼清單請參考 此檔案 。
ele-1: All FHIR elements must have a @value or children
- 使用方式可參考： https://www.nhi.gov.tw/ch/dl-73487-76c892dbc278458ca07b63efa5ffd853-1.pdf
- HapiFhir Instance Validator: 驗證FHIR資料是否符合指定的FHIR Profile規格
-
fhir-validator-must-support: 驗證FHIR資料是否有Must Support欄位 (使用驗證器gitHub)
• 注意: 目前只能驗單一Resource
